v² eagle™

The NRI v² eagle™ coin validator is setting standards with its high security, highly flexible architecture. This 5” format coin validator offers mft™ validation technology providing for the highest coin security available as well as different coin entry and sorting options for the most flexible solution. The anti-jam sensor for quick coin insertion makes this the ideal unit for a wide variety of applications where speed is important.

With manipulation protection, modular construction and unique mft validation technology, this validator will continue to set the standards in the 5” category for years to come.

Benefits

Industry-leading security by simultaneously processing 24 coin parameters coupled with unique mft technology

Anti-jam sensor comes standard for fast coin insertion

Flexible design offers top or front coin entry versions and optionally integrated 4- or 5-way in-line or cross sorter mechanism

Mobile service tool HENRI+ for quick on-site device and coin configuration updates

Protection against string manipulation

Optical monitoring of coin path for higher security

Inhibit of single coins or coin groups through dip switches

Specifications

Coin Insertion
Single coin, top or front entry
Coin Speed (coin/s)
2 Coins per second
Dimensions (H x W x D in mm)
Dimensions (HxWxD) 181.3mm x 127mm x 64mm
Industry Format
5.25 inch
Coin Sorting
Internal 5-way-in-line sorter, internal 4-way sorter, internal 5-way cross sorter, optional / external 8-way sorter
Operating Temperature
0°C - 60°C
Coin Processing
32 coins max. in 2 x 16 channels
15–31 mm (optional up to 32 mm with thickness of max. 2.4 mm)
1.5mm – 2.4mm (optional up to 3.4mm)
Front Plate
Available for front entry
Interfaces Supported
Parallel: 16-pin BDTA version, 17-pin BACTA version
Serial: ccTalk standard or ACMI according to Italian gaming machine act, also in combination with USB
Serial: S1 version according to MDB standard
Supply Voltage
10 - 24 V DC

Variants

eagle 4 way

Internal 4-way or 5-way Sorting Mechanism

  • v² eagle with 4-way sorting mechanism
  • v² eagle with 5-way in-line sorting mechanism (sorting chutes arranged behind one another)
  • v² eagle with 5-way cross sorting mechanism (sorting chutes arranged beside one another, not in combination with front entry version)
  • 4-way sorting manifold for 4-way and 5-way inline sorting mechanisms
  • Active 8-way sorting manifold for 4-way sorting mechanism
manipulation protection logo

Manipulation Protection

  • Optical string detector protecting against both tight and loose strings
  • Customer-specific protocol encryptions
coin entry and outlet

Coin Entry and Outlet

  • Top entry & bottom return
  • Front entry & bottom return
  • Front entry & front return
  • Suitable front plate accessories

Accessories

Firmware Update Tools

Firmware Update Tools (v² eagle)

  • Mobile HENRI+ service tool for on-site uploads
  • CXFlash PC application for back-office uploads
Configuration Tools

Configuration Tools (v² eagle)

  • Mobile HENRI+ service tool for on-site configuration uploads
  • heartbeat PC application for back-office detail configuration
Test Tools

Test tools (v² eagle)

  • ccTalk DemoPC application for testing coin acceptance of v² eagle ccTalk
  • WinSPT PC application for testing coin acceptance and interfaces of serial v² eagle
System Integrators

System Integrators (v² eagle)

  • i² Mini Hub
  • a² long channel coin changer housing
  • Payment Manager program library for serial coin validators
  • NRIHIDAPI.dll program library for serial coin validators
Sorters

Sorters (v² eagle)

  • 4-way sorting manifolds (not for v² eagle with cross sorting mechanism)
  • Active 8-way sorting manifold for v² eagle with 4-way sorting mechanism
Front Plates

Front Plates (v² eagle)

  • For front entry & bottom return version
  • For front entry & front return version
Escrow

Escrow

e² escrow for coin collection and deflection to cashbox or return area
